The StemAids Three-Dimensional Agitator is a laboratory shaking and mixing instrument designed to provide gentle 3D rocking motion for uniform sample agitation. It is suitable for educational laboratories, research laboratories, biotechnology labs, clinical laboratories, pharmaceutical testing units, and institutional science lab setups.
Product Description
The StemAids Three-Dimensional Agitator is designed for smooth, controlled, and uniform mixing of samples placed in flasks, culture plates, petri dishes, tubes, staining trays, and compatible laboratory vessels. Its three-dimensional rocking motion helps distribute liquids evenly across the container surface without aggressive shaking.
This agitator is especially useful for gel staining and destaining, cell culture handling, DNA extraction workflows, washing procedures, reagent mixing, sample incubation support, and general laboratory agitation. The digital control system with LCD display allows users to monitor speed and time, supporting repeatable laboratory procedures in teaching, research, and quality-control environments.
Key Features
- Gentle three-dimensional rocking motion for uniform sample agitation.
- Fixed 9° tilt angle for stable and controlled mixing action.
- Digital LCD display for speed and timer monitoring.
- Adjustable speed control for different laboratory applications.
- Timer function for repeatable and controlled agitation periods.
- Anti-slip platform surface for improved sample stability.
- Compatible with different platform accessories as per application requirement.
- Suitable for flasks, dishes, tubes, trays, culture plates, and sample containers.
- Incubator-compatible design for temperature-controlled laboratory workflows.
- Compact benchtop design suitable for educational and professional laboratories.
Product Specifications
| Product Name | Three-Dimensional Agitator |
|---|---|
| Brand | StemAids |
| Reference Type | Digital 3D shaker / three-dimensional laboratory agitator |
| Motion Type | 3D rocking motion |
| Tilt Angle | 9° |
| Speed Range | 10-70 rpm |
| Speed Display | LCD |
| Timer Display | LCD |
| Timer Range | 1 minute to 19 hours 59 minutes |
| Maximum Load Capacity | Up to 5 kg with platform |
| Motor Type | DC motor |
| Motor Input Power | Approx. 40 W |
| Motor Output Power | Approx. 24 W |
| Total Power | Approx. 50 W |
| Voltage / Frequency | 100-240 V, 50/60 Hz |
| Platform Surface | Anti-slip platform surface |
| Work Plate Dimension | Approx. 300 × 285 mm |
| Overall Dimension | Approx. 360 × 430 × 106 mm |
| Approximate Weight | Approx. 9 kg |
| Protection Class | IP21 |
| Permissible Ambient Temperature | 5°C to 40°C |
| Permissible Relative Humidity | Up to 80% RH |
| Application Area | Biology labs, biotechnology labs, clinical labs, pharmaceutical labs, research labs, and educational laboratories |
Applications
- Gel staining and destaining procedures.
- DNA extraction and molecular biology workflows.
- Cell culture sample handling.
- Washing and incubation support procedures.
- Mixing of reagents, buffers, and biological samples.
- Uniform agitation of petri dishes, culture plates, and trays.
- Sample preparation in research and clinical laboratories.
- Educational demonstrations in school, college, and university laboratories.
How to Use the Three-Dimensional Agitator
- Place the agitator on a clean, dry, flat, and stable laboratory bench.
- Connect the instrument to the recommended power supply.
- Select a suitable platform or accessory according to the sample container type.
- Place flasks, petri dishes, trays, plates, or tubes evenly on the platform.
- Ensure that the total sample load does not exceed the recommended load capacity.
- Secure samples using the available platform mat, strings, clips, or compatible holders where required.
- Switch on the unit and set the required agitation speed using the control panel.
- Set the timer if a fixed agitation period is required.
- Start the agitator and observe the first few movements to ensure stable operation.
- After the process is complete, stop the instrument before removing samples.
- Clean the platform and external surface after use according to laboratory cleaning procedures.
Safety and Handling Guidelines
- Do not exceed the recommended load capacity of the platform.
- Place samples evenly to maintain proper balance during agitation.
- Use closed or properly covered containers when working with liquids.
- Do not touch or adjust samples while the platform is moving.
- Keep the instrument away from water splashes, corrosive vapours, and unstable surfaces.
- Wear suitable laboratory PPE such as gloves, safety goggles, and a lab coat.
- Disconnect the power supply before cleaning or changing accessories.
- Use the instrument under trained laboratory supervision.
Why Choose StemAids Three-Dimensional Agitator?
StemAids supplies laboratory instruments for educational institutions, research laboratories, diagnostic facilities, and institutional procurement projects. The Three-Dimensional Agitator is designed for controlled sample agitation, repeatable digital settings, and gentle laboratory mixing performance.
- Suitable for biology, biotechnology, clinical, and pharmaceutical laboratories.
- Digital speed and timer display supports repeatable laboratory procedures.
- Gentle 3D rocking motion helps reduce sample disturbance.
- Useful for gel staining, culture work, washing, and sample preparation.
- Compact benchtop design suitable for routine laboratory workflows.
- Procurement-friendly product details for quotations, catalogues, and institutional tenders.
Technical Note
Three-dimensional agitation is preferred when samples require gentle and uniform movement across a broad surface area. It is commonly selected for staining trays, culture plates, petri dishes, and sample containers where vigorous orbital shaking or vortex mixing may not be suitable.
Frequently Asked Questions
1. What is a Three-Dimensional Agitator used for?
It is used for gentle and uniform agitation of samples in flasks, trays, tubes, petri dishes, culture plates, and laboratory vessels.
2. What is the benefit of 3D rocking motion?
3D rocking motion distributes liquid evenly across the sample container, making it useful for staining, washing, mixing, and incubation support procedures.
3. What is the speed range of the agitator?
The reference digital three-dimensional agitator offers an adjustable speed range of 10-70 rpm.
4. Does the agitator have a timer?
Yes. The unit includes a timer function with a reference range of 1 minute to 19 hours 59 minutes.
5. What is the maximum load capacity?
The reference model supports a maximum load capacity of up to 5 kg with platform.
6. Can it be used inside an incubator?
Yes. The reference design is incubator-compatible, provided the operating temperature and humidity remain within the recommended limits.
7. Is it suitable for school and college laboratories?
Yes. It is suitable for biology labs, biotechnology labs, chemistry labs, STEM laboratories, college practical work, and university research applications.
8. Which sample containers can be used?
It can be used with compatible flasks, petri dishes, culture plates, staining trays, tubes, and sample containers depending on the selected platform accessory.
9. How should the agitator be cleaned?
Switch off and disconnect the instrument before cleaning. Wipe the platform and exterior surface with a soft cloth and mild laboratory-safe cleaning solution. Do not immerse the instrument in water.
