In Stock
Immersion thermostat TI-05
₹9,850.00
The StemAids Immersion Thermostat TI-05 is a compact laboratory temperature-control unit designed for automatic heating and temperature regulation of laboratory tanks, water baths, and liquid-based experimental setups. It is suitable for chemistry, biology, pharmaceutical, research, academic, and quality-control laboratories where stable liquid temperature is required.
Product Description
The StemAids Immersion Thermostat TI-05 is used to regulate the temperature of liquids in compatible laboratory tanks. It includes a heating element, integrated stirring system, digital temperature regulation, and a universal clamping arrangement for easy mounting on suitable tanks.
The unit is suitable for maintaining controlled bath temperature during incubation, chemical reactions, sample preparation, thermal testing, reagent warming, and educational laboratory practicals. Its stainless-steel liquid-contact parts and compact design make it practical for frequent laboratory use.
Key Features
- Automatic temperature control for laboratory tanks and water baths
- Temperature range from ambient +5°C to 100°C
- Digital temperature regulation with 0.1°C display resolution
- Integrated stirring for improved liquid temperature uniformity
- 710 W heating power for efficient laboratory heating applications
- Universal clamping system for mounting on compatible tanks
- Stainless-steel liquid-contact parts for durability and easy cleaning
- DIN 12879 safety thermostat protection against overheating
- Suitable for educational, analytical, research, and industrial laboratory use
Product Specifications
| Product Name | StemAids Immersion Thermostat TI-05 |
|---|---|
| Brand | StemAids |
| Reference Model | TI-05 |
| Product Type | Immersion Thermostat / Laboratory Tank Temperature Controller |
| Temperature Range | Ambient +5°C to 100°C |
| Resolution | 0.1°C |
| Temperature Accuracy | ±0.1°C |
| Hysteresis | 0.25°C |
| Heating Power | 710 W |
| Voltage | 230 V, 50/60 Hz |
| Electrical Insulation | Class I |
| Protection Rating | IP33 as per DIN EN 60529 |
| Maximum Tank Volume | Up to 9 litres |
| Maximum Tank Wall Thickness | 10 mm |
| Liquid-Contact Material | Stainless steel |
| Housing | Painted metal housing |
| Permissible Ambient Temperature | +4°C to +40°C |
| Permissible Relative Humidity | Up to 80% |
| Dimensions | 160 mm depth x 150 mm height x 90 mm width |
| Weight | Approx. 3 kg |
| Safety Feature | DIN 12879 certified safety thermostat for overheating protection |
| Recommended Users | Schools, colleges, universities, R&D labs, pharmaceutical labs, QC labs, and industrial laboratories |
How to Use StemAids Immersion Thermostat TI-05
- Select a compatible laboratory tank with suitable liquid capacity and wall thickness.
- Fill the tank with the recommended liquid medium according to the experiment requirement.
- Mount the TI-05 thermostat securely on the tank using the universal clamping system.
- Ensure the heating element and stirring section are properly immersed in the liquid.
- Connect the thermostat to a suitable 230 V power supply.
- Set the required temperature using the digital regulator.
- Allow the integrated stirring system to circulate the liquid and improve temperature uniformity.
- Place samples, vessels, or accessories in the bath as per the laboratory procedure.
- Monitor the temperature and experiment throughout operation.
- After use, switch off the thermostat, disconnect power, allow the liquid to cool, and clean the unit safely.
Applications
- Laboratory water bath temperature control
- Sample incubation and thermal conditioning
- Chemical reaction temperature maintenance
- Biology and microbiology laboratory workflows
- Reagent warming and solution preparation
- Material testing and controlled heating procedures
- School, college, and university laboratory practicals
- Research, pharmaceutical, and quality-control testing
Why Choose StemAids?
StemAids supplies practical laboratory equipment for educational institutions, research laboratories, and professional testing environments. The StemAids Immersion Thermostat TI-05 is suitable for users who need precise, compact, and procurement-ready temperature-control equipment for compatible tanks and bath applications.
- Suitable for academic, research, pharmaceutical, and QC laboratories
- Useful for accurate water bath and liquid temperature control
- Compact design for easy placement in laboratory setups
- Clear technical specifications for quotations and tenders
- Designed for supervised laboratory heating and thermal regulation workflows
Care and Safety Instructions
- Use only with compatible tanks and suitable laboratory liquids.
- Do not operate the thermostat without proper liquid immersion.
- Do not exceed the recommended tank volume and wall thickness.
- Always ensure the clamp is securely fixed before switching on the unit.
- Do not touch hot liquid, heating parts, or the tank during operation.
- Use heat-resistant gloves and proper laboratory PPE when required.
- Clean stainless-steel parts after use and remove chemical residue safely.
- Disconnect power before cleaning, adjustment, or storage.
- Use under trained supervision in educational and professional laboratories.
SEO Keywords
Immersion thermostat TI-05, StemAids immersion thermostat, laboratory immersion thermostat, water bath thermostat, laboratory tank temperature controller, digital immersion thermostat, 100°C immersion thermostat, laboratory heating thermostat, stainless steel immersion thermostat, water bath temperature control, chemistry lab thermostat, biology lab water bath controller.
Frequently Asked Questions
What is the StemAids Immersion Thermostat TI-05 used for?
It is used for automatic temperature control of laboratory tanks, water baths, and liquid-based experimental setups.
What is the temperature range of the TI-05?
The temperature range is ambient +5°C to 100°C.
What is the heating power of this immersion thermostat?
The heating power is 710 W.
What tank capacity is suitable for this thermostat?
It is suitable for compatible tanks up to 9 litres with a maximum wall thickness of 10 mm.
Does the TI-05 have overheating protection?
Yes, it includes a DIN 12879 safety thermostat designed to help prevent overheating.
Can it be used in school and college laboratories?
Yes, it is suitable for school, college, university, and training laboratories when used under proper supervision.
Does it circulate the liquid?
Yes, the integrated stirring system helps circulate the liquid and improve temperature uniformity inside the tank.
What should be checked before ordering?
Confirm the model TI-05, required voltage, tank volume, tank wall thickness, temperature range, application, and compatibility with the intended laboratory setup.
